Linear Actuators

High-performance contractile artificial muscle actuators

Stronger, Lighter, Smaller

Pound for pound, Adaract’s artificial muscle actuators contract with more force than any other linear actuator–without sacrifices to range of motion, durability, or efficiency.

By combining high pressure hydraulics, advanced synthetic materials, and proprietary manufacturing, Adaract has achieved unprecedented performance in linear actuation.

Adaract’s actuator performance and how it interfaces with existing systems can be fully customized. An actuator’s length or fiber count can be adjusted, as can its hydraulic fittings and mechanical connections.

high performance artificial muscle actuator

Unparalleled Performance

  1. High Pressure Operation

    Suitable for continuous operation at 3,000 psi, with burst pressures of 9,000 - 10,000 psi

  2. Lightweight Strength

    Contraction force to actuator weight ratios of up to 20,000 : 1 are possible at 3,000 psi. as a standard 8” fiber weighs less than a penny

  3. Compliance

    Well suited for impedance control and as flexible as a shoestring, even in bundles

  4. Zero-drip Operation

    Provides zero-drip operation and compatibility with common aerospace hydraulic fluids such as Skydrol™ and Chemolube®

  5. Durability in Extreme Environments

    Adaract’s actuators can be configured to provide extreme corrosion resistance to salt solutions and humid environments.

  6. Fully Customizable

    Can be designed and manufactured in bundles of any number of fibers at any length to perfectly fit your specific application

  • Working Pressure: 3,000 PSI

    Burst Pressure: 10,000 PSI (typical)

    Min. Contractive Pressure: 150 PSI

    Displacement (single 8” fiber): 0.4 mL

    Contraction Speed: 50 milliseconds min.

    Cycles to Failure: >1,000,000*

    Weight (single 8” fiber): ~2 grams

    Weight (bundles): ~1.3 grams per 8” fiber

    Compatible Working Fluids: Skydrol™ and Chemolube®, Silicone Oil **

    *For AM70 models

    **Please contact Adaract if your application requires the use of alternative working fluids.

  • Product Data Sheets

Achieve Your Functional Goals

Compact, energy efficient robotics

Reduce size, improve battery life, or reduce energy cost in robotic systems

Weight reduction where it matters

Significantly reduce weight when compared to industry leading hydraulic actuators

Compliant, bio-mimetic motion

Optimize wearables, bio-mimetic systems, and more without sacrificing performance

Related Products

Hydraulic Power Units

Ultra compact Hydraulic Power Units for maximum weight/size reduction

variable recruitment actuator

Variable Recruitment Systems

Multi-fiber manifolds & valves to improve energy efficiency and control of Adaract actuators

turnkey actuation system

Turnkey Actuation Systems

Customized combinations of Adaract systems for easy implementation
